Get ready to escape the busyness of life in an Ascape Aliner travel trailer. These models are the lightest travel trailer in its class, and also the easiest to pull behind any vehicle. The aerodynamic design gives each trailer a sleek and stylish look, while being economical.



Inside an Ascape you will find all of the amenities that you would expect on any trailer of this size. The dinette in each model doubles as your bed at night, and you will find a kitchen area for preparing meals, plus there is an air conditioner, furnace, and even a 23" flat screen TV. For the couple who enjoys the simpler side of camping, and would like to sleep off of the ground, an Ascape travel trailer by Aliner may be ideal for you!

  • Ascape Great ST

    Ascape Great ST Floorplan Image

    ALiner Ascape travel trailer Great ST highlights: Wet Bath Deep Bowl Euro Sink ... more about Ascape Great ST

    Specifications

    Sleeps 2
    Length 14 ft
    Ext Width 6 ft 7 in
    Ext Height 8 ft 4 in
    Int Height 6 ft 4 in
    Hitch Weight 220 lbs
    Dry Weight 1850 lbs
    Cargo Weight 650 lbs
    Fresh Water Capacity 11 gals
    Grey Water Capacity 13 gals
    Tire Size 185/80 R13
    Furnace BTU 18000 btu
    Refrigerator Type Three Way
    Refrigerator Size 3 cu ft
    Cooktop Burners 2
    Number of Awnings 1
    Axle Weight 2500 lbs
    LP Tank Capacity 20 lbs
    Water Heater Capacity 6 gal
    Water Heater Type Suburban
    AC BTU 9200 btu
    TV Info 23" Flat Screen TV
    Awning Info 6' Thule
    Axle Count 1
    Number of LP Tanks 2
    Shower Type Wet/Bath Shower

    Similar Floorplans

  • Ascape Camp

    Ascape Camp Floorplan Image

    ALiner Ascape travel trailer Camp highlights: Cabinet/Wardrobe Two Burner Stove ... more about Ascape Camp

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 2
    Length 13 ft
    Ext Width 6 ft 1 in
    Ext Height 8 ft 4 in
    Int Height 6 ft 4 in
    Hitch Weight 229 lbs
    Dry Weight 1495 lbs
    Cargo Weight 1005 lbs
    Fresh Water Capacity 11 gals
    Grey Water Capacity 13 gals
    Furnace BTU 16000 btu
    Refrigerator Type Three Way
    Refrigerator Size 1.9 cu ft
    Cooktop Burners 2
    Axle Weight 2500 lbs
    LP Tank Capacity 20 lbs
    Water Heater Capacity 6 gal
    Water Heater Type Suburban
    AC BTU 9200 btu
    Axle Count 1
    Number of LP Tanks 1

    Similar Floorplans

  • Ascape Grand Ascape Plus

    Ascape Grand Ascape Plus Floorplan Image

    ALiner Ascape Grand Ascape Plus travel trailer highlights: Cassette Toilet Two ... more about Ascape Grand Ascape Plus

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 2
    Length 14 ft
    Ext Width 6 ft 7 in
    Ext Height 8 ft 4 in
    Int Height 6 ft 4 in
    Hitch Weight 230 lbs
    Dry Weight 1750 lbs
    Cargo Weight 750 lbs
    Fresh Water Capacity 11 gals
    Grey Water Capacity 13 gals
    Tire Size 185/80 R13
    Furnace BTU 18000 btu
    Refrigerator Type Three Way
    Refrigerator Size 3 cu ft
    Cooktop Burners 2
    Axle Weight 2500 lbs
    LP Tank Capacity 20 lbs
    Water Heater Capacity 6 gal
    Water Heater Type Suburban
    AC BTU 9200 btu
    TV Info 23" Flat Screen TV
    Axle Count 1
    Number of LP Tanks 2
  • Ascape Grand Ascape ST

    Ascape Grand Ascape ST Floorplan Image

    ALiner Ascape Grand Ascape ST travel trailer highlights: Wet Bath Two Burner ... more about Ascape Grand Ascape ST

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 2
    Length 14 ft
    Ext Width 6 ft 7 in
    Ext Height 8 ft 4 in
    Int Height 6 ft 4 in
    Hitch Weight 225 lbs
    Dry Weight 1700 lbs
    Cargo Weight 800 lbs
    Fresh Water Capacity 11 gals
    Grey Water Capacity 13 gals
    Tire Size 185/80 R13
    Furnace BTU 18000 btu
    Refrigerator Type Three Way
    Refrigerator Size 3 cu ft
    Cooktop Burners 2
    Axle Weight 2500 lbs
    LP Tank Capacity 20 lbs
    Water Heater Capacity 6 gal
    Water Heater Type Suburban
    AC BTU 9200 btu
    TV Info 23" Flat Screen TV
    Axle Count 1
    Number of LP Tanks 2
    Shower Type Wet/Bath Shower
  • Ascape Great Plus

    Ascape Great Plus Floorplan Image

    ALiner Ascape travel trailer Great Plus highlights: Deep Bowl Euro Sink U-Shaped ... more about Ascape Great Plus

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 2
    Length 14 ft
    Ext Width 6 ft 7 in
    Ext Height 8 ft 4 in
    Int Height 6 ft 4 in
    Hitch Weight 240 lbs
    Dry Weight 1900 lbs
    Cargo Weight 600 lbs
    Fresh Water Capacity 11 gals
    Grey Water Capacity 13 gals
    Tire Size 185/80 R13
    Furnace BTU 18000 btu
    Refrigerator Type Three Way
    Refrigerator Size 3 cu ft
    Cooktop Burners 2
    Number of Awnings 1
    Axle Weight 2500 lbs
    LP Tank Capacity 20 lbs
    Water Heater Capacity 6 gal
    Water Heater Type Suburban
    AC BTU 9200 btu
    TV Info 23" Flat Screen TV
    Awning Info 6' Thule
    Axle Count 1
    Number of LP Tanks 2

    Similar Floorplans

  • Ascape MT

    Ascape MT Floorplan Image

    ALiner Ascape travel trailer MT highlights: Frameless Windows Zamp Solar Port ... more about Ascape MT

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 2
    Length 13 ft
    Ext Width 6 ft 1 in
    Ext Height 8 ft 4 in
    Int Height 6 ft 4 in
    Hitch Weight 190 lbs
    Dry Weight 1170 lbs
    Cargo Weight 1330 lbs
    Axle Weight 2500 lbs
    Axle Count 1

    Similar Floorplans

  • Ascape Plus

    Ascape Plus Floorplan Image

    ALiner Ascape Plus travel trailer highlights: Deep Bowl Sink Two Burner Cooktop ... more about Ascape Plus

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 2
    Length 13 ft
    Ext Width 5 ft 6 in
    Ext Height 8 ft 4 in
    Int Height 6 ft 4 in
    Hitch Weight 170 lbs
    Dry Weight 1500 lbs
    Cargo Weight 1000 lbs
    Fresh Water Capacity 11 gals
    Grey Water Capacity 13 gals
    Furnace BTU 16000 btu
    Refrigerator Type Three Way
    Refrigerator Size 3.0 cu ft
    Cooktop Burners 2
    Number of Awnings 1
    Axle Weight 2500 lbs
    LP Tank Capacity 20 lbs
    Water Heater Capacity 6 gal
    Water Heater Type Surburban
    AC BTU 9200 btu
    TV Info 23" Flat Screen TV
    Awning Info 5' Carefree
    Axle Count 1
    Number of LP Tanks 2
  • Ascape ST

    Ascape ST Floorplan Image

    ALiner Ascape travel trailer ST highlights: Wet Bath Two Burner Stove Sink ... more about Ascape ST

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 2
    Length 13 ft
    Ext Width 6 ft 1 in
    Ext Height 8 ft 4 in
    Int Height 6 ft 4 in
    Hitch Weight 220 lbs
    Dry Weight 1575 lbs
    Cargo Weight 925 lbs
    Fresh Water Capacity 11 gals
    Grey Water Capacity 13 gals
    Furnace BTU 16000 btu
    Refrigerator Type Three Way
    Refrigerator Size 1.9 cu ft
    Cooktop Burners 2
    Axle Weight 2500 lbs
    LP Tank Capacity 20 lbs
    Water Heater Capacity 6 gal
    Water Heater Type Suburban
    AC BTU 9200 btu
    Axle Count 1
    Number of LP Tanks 1
    Shower Type Wet/Bath Shower

    Similar Floorplans

Ascape Features:

Standard Features (2020)



  • LED Running Lights
  • Automotive Finish
  • 10" Electric Brakes
  • Robotically welded, E-coated frame
  • 13" Aluminum Wheels with full size spare
  • Dexter 2500lb independent torsion axle
  • 4 Stabilizer Jacks
  • 13 Gallon Grey Water Tank
  • E-Z lube hubs
  • 18000 btu Furnace
  • Suburban 6 gallon porcelain lined water heater
  • Shurflo Electric Water Pump
  • Shurflo Electric Water Pump
  • Detachable power cord
  • Dropped Floor for increased Interior Height
  • Solid Maple Hard-Wood Cabinet Doors

Exterior

  • Color Coordinated Graphics and Wheel Well Trim
  • Outside Shower
  • Front Mounted Solar Panel Watts - 50
  • Zamp Solar Port
  • Awning - 4' Carefree (Ascape Plus)
  • Awning - 6' Thule (Grand Ascape ST, Grand Ascape Plus)
  • Plastoform Insulated Double Pane Windows
  • Perimeter TPO Color Coordinated Plastic Trim Package (N/A on Plus) (Optional on Grand Ascape ST and Grand Ascape ST)

Interior

  • Deep Bowl Sink with Pull-Out Faucet (Ascape Plus)
  • Standard Sink with Stationary Faucet ( Grand Ascape Plus and Grand Ascape ST)
  • Enclosed Shower and Toilet Combination (Grand Ascape ST Only)
  • Cassette Toilet
  • 23" Flat Screen TV
  • King Jack Digital TV Antenna (N/A Ascape Plus)

Appliances

  • Atwood 18,000 BTU furnace
  • Dometic 3-Way refrigerator - 30 Cu. Ft.
  • Suburban 6 gal. Porcelain Lined Water Heater
  • Two Burner Range Top (N/A Grand Ascape Plus)
  • Range Hood w/Vent Fan
  • Shurflo Electric Water Pump
  • Coleman Mach 8 - 9,200 BTU Roof Mounted A/C

Chassis

  • Dual 20 lbs. LP Tanks w/Auto Changeover
  • 2,500 lbs. Dexter Torsion Axle

Please see us for a complete list of features and available options!

All standard features and specifications are subject to change.









Manu-Facts:

ALiner Logo
In the early 1970s, Ralph Tait had an idea. So he went into his garage in Bend, Oregon and began tinkering. Several weeks and a few blisters later, he emerged with a revolutionary design for the first A-frame pop-up camper.

It was sensible. It was different. And it was light enough to be towed with just about any vehicle. Friends wanted one. Family wanted one. Friends of family wanted one. As word of mouth spread, Ralph found himself making more campers out of his garage. That’s when Ralph’s sons had their own bright idea. Why not turn this hobby into a real business?

The family moved to Pennsylvania and began making Aliner campers. Two brothers would build one. The third brother would hitch it to the family station wagon and drive across the country until he sold it. When he returned, the brothers would have another Aliner waiting. After years of hard work and several hundred thousand miles on the poor station wagon, the family retired in 2007. Today we continue to build every Aliner with the same quality, craftsmanship and pride as Ralph and his sons did for over 30 years.
